VMC-1370 maching center

Vmc-1370 vertical machining center, x, y and Z axes are servo direct control semi closed-loop vertical structure, the three axes are high rigid rectangular guide rails, and the sliding surface with large guide load, wide span and high precision is pasted with plastic. The main shaft is driven by servo motor through synchronous belt, which can realize one-time clamping of various discs, plates, shells, cams, molds and other complex parts, and can complete drilling, milling, boring, expanding It is suitable for the production of multi variety, medium and small batch products, and can meet the processing of complex and high-precision parts.

1. The head group is a heavy-duty box structure with reinforced internal ribs and high rigidity.
2. Pneumatic cutting is adopted for the main shaft. During cutting, the main shaft is stressed evenly to prolong the service life of the bearing.
3. The electrical box adopts the separated design to separate the heat source of the controller, and the heat exchanger is used in front to dissipate heat to prevent external dust from entering the electrical box; The rear side uses a fan to dissipate heat for the fan hot plate.
4. The three-axis adopts Taiwan Shangyin high-precision ball screw, combined with precision nut preloading and tail end pretensioning device to ensure that the back clearance and thermal deformation of the machine are kept at a low value for a long time.
5. X, y and Z axes adopt ball type linear guide rail, which has high rigidity, low noise and low friction. It can be used for rapid displacement and obtain the best cycle accuracy.
6. All finished products are subject to laser positioning correction and circular test. To ensure the best positioning accuracy and servo characteristics. In addition, the machine tool is subject to strict inspection measures before shipment to ensure the long-term stability of various accuracy of the machine.
